Type Designator: STW48N60M2
Marking Code: 48N60M2
Type of Transistor: MOSFET
Type of Control Channel: N -Channel
Pdⓘ – Maximum Power Dissipation: 300 W
|Vds|ⓘ – Maximum Drain-Source Voltage: 600 V
|Vgs|ⓘ – Maximum Gate-Source Voltage: 25 V
|Vgs(th)|ⓘ – Maximum Gate-Threshold Voltage: 4 V
|Id|ⓘ – Maximum Drain Current: 42 A
Tjⓘ – Maximum Junction Temperature: 150 °C
Qgⓘ – Total Gate Charge: 70 nC
trⓘ – Rise Time: 17 nS
Cossⓘ – Output Capacitance: 143 pF
Rdsⓘ – Maximum Drain-Source On-State Resistance: 0.07 Ohm
Package: TO-247
